Description
TCST2103 optical sensor – slot optocoupler
Application: for optoelectronic sensing and switching, such as color character detection, coding disk readout, non-contact switches, tape break detectors, tachometers and speedometers.
Technical data
| Further technical data | Input: GaAs-IR-Lumin.-diode |
| Available in PCB software | Target 3001! |
| Return voltage emitter U(CEO) | 70 V |
| I(C) | 4 mA |
| I(F) | 60 mA |
| Voltage in the conduction direction U(F) | 1.25 V |
| Specification | GaAs-IR-Lumin.-diode |
| Net width | 6.3 mm |
| Slot width | 3.1 mm |
| Type | TCST 2103 |
| Output (ampere) | NPN phototransistor |
| Net height | 10.8 mm |
| Range | 3.1 mm |
Included
- Motion sensor HC-SR505 – 1 pc.
